| Unità vendibili | : | roll |
| Tipo pacchetto | : | Nel marchio rotolo / impermeabile di carta / plastidip |
| Esempio immagine | : |
|
The file is encrypted. Please fill in the following information to continue accessing it
|
PRODUCT CATEGORY
|
PRICE
|
PRODUCT LIFE
|
AMOUNT OF ZINC COATED
|
|
Electric Galvanized Before Welded Wire Mesh
|
Most cheap one
|
4 years
|
≤10 microns
|
|
Electric Galvanized After Welded Wire Mesh
|
|
7 years
|
15-30 microns
|
|
Hot-dipped Galvanized Welded Wire Mesh
|
Most expensive one
|
10 years
|
Around 100 microns
|
|
Raw Material
|
Chemical composition
|
|
|
|
|
Physical properties
|
|
Process Properties
|
|||||
|
Q195
（Low Carbon Steel)
|
C
|
S
|
SI
|
Mn
|
P
|
Rm（Mpa）
|
A/%
|
Cold bend 180°
|
|||||
|
|
0.06
|
0.025
|
0.09
|
0.32
|
0.026
|
350
|
34.0
|
Qualified
|
|||||
|
HOLE SIZE (MESH)
|
|
WIRE DIAMETER
|
PACKING Dia.(mm)
|
Width/Length
|
||||
|
1/4" x 1/4"
|
6.35mm x 6.35mm
|
BWG 14-25
|
215
|
3' x 100'
4' x 100'
5' x 100'
|
||||
|
3/8" x 3/8"
|
9.53mm x 9.53mm
|
|
250
|
|
||||
|
1/2" x 1/2"
|
12.7mm x 12.7mm
|
|
230-300
|
|
||||
|
5/8" x 5/8"
|
15.87mm x 15.87mm
|
|
260
|
|
||||
|
3/4" x 3/4"
|
19.05mm x 19.05mm
|
|
240-350
|
|
||||
|
1" x 1"
|
25.4mm x 25.4mm
|
|
255-400
|
|
||||
|
1" x 1/2"
|
25.4mm x 12.7mm
|
|
265-335
|
|
||||
|
1" x 2"
|
25.4mm x 50.8mm
|
|
310-390
|
|
||||
|
2" x 2"
|
50.8mm x 50.8mm
|
|
|
|
||||
|
4" x 4"
|
101.6mm x 101.6mm
|
|
|
|
||||
|
6" x 6"
|
152.4mm x 152.4mm
|
|
|
|
||||
|
Accept customization
|
|
|
|
|
||||
|
item
|
value
|
|
Place of Origin
|
HEB
|
|
Brand Name
|
HY
|
|
Model Number
|
1/2",3/4",1",1/4",3/8"
|
|
Application
|
Fence
|
|
Material
|
low carbon steel wire q235,q195,stainless steel,carbon steel, copper, aluminum
|
|
Wire Gauge
|
0.4-2.5mm
|
|
Hole Shape
|
Square
|
|
Surface Treatment
|
galvanized
|
|
Technique
|
Welded
|
|
Processing Service
|
Welding
|
|
Delivery Time
|
22-30 days
|
|
Mesh Hole
|
1",1/2"
|
|
Usage
|
Animal Fencing
|
|
Meterial
|
Q235wire/Stianless Steel
|
|
Wire diameter
|
0.6mm-2mm
|
|
Surface
|
Electrol Galvanized
|
|
Keywords
|
Welded Gabions Fence
|
|
Feature
|
Long-life
|
|
Packing
|
Water-proof Paper + Plastic Film
|
